RayBit Live Streaming Camera SC1

$199.00

What sets SC1 apart is its exceptional wireless capabilities. Thanks to advanced RTMP and NDI streaming protocols, you can experience stable, low latency high-speed streaming without the limitation of cables. Plus, with up to 2.5K resolution and 30FPS high speed transmission, you can create stunning video from anywhere, cable-free. Enjoy the freedom of wireless streaming with SC1 .

● AI face tracking.

● 4K camera.

● 2 microphone arrays.

● Support 3 Wireless Live Streaming.

● NDI Wireless Streaming.

● 3000 mAh battery

● Voice Pickup Range Up to 3 meters.

● USB connection,driver free.

Shipping & Returns

Make sure to read and understand the return policy before making a purchase. Some stores offer free returns, while others may charge a restocking fee or only accept returns for certain items.

Compatibility

The connectivity options of your device are also essential to consider. For example, if you're purchasing a printer, you need to ensure that it is compatible with your computer's connectivity options, such as USB, Bluetooth, or Wi-Fi.

RayBit Live Streaming Camera SC1

Full HD Camera:Video resolution up to 2K,90° wide view angle with automatic color balance, everyone clearly presented in the scene.

Ai auto framing:With Ai auto framing and facial tracking feature, it will
follow your movements and always keep you at center stage.

Built in microphone array:Built - in Microphone array for 360° voice pick up radius to 3-5 meters, wide coverage and clear reception.

Long battery life:Built-in 3000mAh battery Up to 6 hours meeting.

3A audio algorithm:With 3A audio algorithm for acoustic echo cancellation, noise suppression and automatic gain control.

Works with most video conferencing applications:Compatible with most of video conferencing software app, like Skype for Business, Zoom, WebEx and so on.

Plug-and-play USB connectivity:Built-in 2meters long USB cable, plug-and-play with any PC or UC platform.

Tech Specs

Camera

  • Sensor:SC530AI
  • Pixel:5 Mega-pixel
  • Pixel Size:2.0μm x 2.0μm
  • Optical format :1/2.7”
  • CRA: 15°
  • Sensitivity:2614mV/LUX*S
  • Dynamic range:
  • 1. HDR mode up to 100dB 2. Linear mode 83dB
  • SNR:40dB

Sensor (Not Final Camera Output)

  • Resolution: 5MP (2884x1624) at 60fps
  • Streaming Out: 10-bit RAW RGB via MIPIm, 1080p@30.
  • Actual output: Likely 8-bit YCbCr, not max sensor resolution.

Memory

  • FLASH type: Nand
  • FLASH capacity: 128MB
  • DDR type: DDR3L
  • DDR capacity: 1G

Battery

  • Build in 3000 mAh battery

Microphone

  • Number of Microphones:2*MIC
  • Directivity:Unidirectional
  • Signal to Noise Ratio:68dB
  • Sensitivity: -34dBFS
  • Distortion (THD):110dB spl at 1khz 3%
  • Voice pick-up range up to 3 meters.

Warranty

  • 1 Year

Supported Systems

  • MacOS® 10.10 or above
  • Android™ v 5.0 or above

Compatibility

  • Compatible with any application that supports standard USB audio and video drivers.

Other features

  • Wireless connection:YES
  • Power adapter:5V2A
  • LED indicator:YES
  • SC1 size:146.2 X 100.3 X 63.6mm
  • Package size: 187 X 137 X 88mm
  • 1 x SC1 Living Streaming Camera
  • 1 x User Manual
  • 1 x Type-C Cable
